Single Phase Thyristor Power Controller
A Single Phase Thyristor Power Controller is a device designed to regulate power in single-phase AC electrical systems. It uses a thyristor to control the phase angle of the AC waveform, allowing precise adjustment of the power delivered to a load, such as heaters, motors, or lighting systems. By controlling when the thyristor is turned on during each AC cycle, the controller can adjust the output power efficiently.
Features and Benefits
- Approximately 10 to 15% power saving.
- More accurate temperature control.
- Improved heater life.
- Least amount of stress on heater element.
- Isolated control section.
- Optional over current tripping.
- Very low & easy for maintenance.
- Also suitable for Inductive Loads.
Technical Specification
| Title | SPECIFICATIONS |
|---|---|
| Model Name/Number | Single Phase Thyristor Power Controller |
| Brand | SAVIK |
| Current Rating | Up to 30 Amps. Higher current ratings will be available on customer's requirment. |
| Usage/Application | For precise heating control. |
| Voltage | 230 V. Ac.,50 Hz. |
| Power Rating | Up to 30 Amps. |
| Accuracy | +/- 2 Deg. cen. of set value. |
| Controller Function Type | Proportional |
